PEX FITTING BRASS MALE ADAPTER (BARB x MPT)
| Back |
|
 |
|
|
Description
Pex Fitting Brass Male Adapter(Barb x Mpt)
Forged brass body
Insert for fittings conform to F1807
Fittings with soldering or brazing end comform to ANSI B16.22
NPT Male Thread, NPSM Female Thread
Thread conform to ANSI/ASME B1.20.1
Designed for residential use with water, oil or air
SPEC.
|
ITEM
|
SIZE
|
INN/MAS
|
|
204-01
|
3/8"P x 1/2"Mpt
|
50/500
|
|
204-02
|
1/2"P x 1/2"Mpt
|
50/500
|
|
204-03
|
1/2"P x 3/4"Mpt
|
25/250
|
|
204-04
|
3/4"P x 3/4"Mpt
|
25/250
|
|
204-05
|
3/4"P x 1/2"Mpt
|
50/500
|
|
204-06
|
1"P x 1"Mpt
|
10/100
|
|
204-07
|
1"P x 3/4"Mpt
|
10/100
|
